Нов (отворена кутия)

ANT-4G-OMNI-OUT-N Cisco Outdoor Omnidirectional Antenna for 2G/3G/4G Cellular 698 to 960 MHz—1.5 dBi 1710 to 2700 MHz—3.5 dBi 360 degrees omnidirectional Нов Отворена Кутия

Cisco C6800IA-48FPD Catalyst 6800 Instant Access POE+ Switch 48x 10/100/1000 Ethernet Ports 2 SFP+ 10G Integrated with IA parent 740W PoE budget УпотребяванL4-25419-01B/06C Cisco LSI Cache Vault Module 74-11165-02 30-100135-01 A0 Употребяван

295 лв.

Състояние: Нов Отворена Кутия

5 in stock

Qty:
Categories: , Tags: , , , , , , , , , , ,

Description


Cisco Outdoor Omnidirectional Antenna for 2G/3G Cellular
Antenna – 1.5 dBi (for 698 – 960 MHz) – 3.5 dBi (for 1.71 – 2.7 GHz) – omni-directional – outdoor – white – for Cisco 2010 – 2010 Connected Grid
Group Antennas
Производител Cisco
Код на производителя ANT-4G-OMNI-OUT-N=
EAN/UPC 0882658486012

Description
The Cisco Outdoor Omnidirectional Antenna for 2G/3G/4G Cellular antenna is designed to cover domestic LTE700/Cellular/PCS/AWS/MDS, WiMAX 2300/2500, and GSM900/GSM1800/UMTS/LTE2600 bands and is supported on the Cisco CGR 2010, 1240, and the 1120 routers.

The Omnidirectional Outdoor Antenna is compatible with Cisco 2G, 3G, and 4G cellular devices that use a Type N connector and requires a mast-mounted outdoor antenna.
Основни характеристики
Описание на продукта Cisco Outdoor Omnidirectional Antenna for 2G/3G Cellular – antenna
Product Type Antenna
Dimensions (WxDxH) 2.5 cm 24.9 cm
Weight 0.68 kg
Product Material Polycarbonate
Colour White
Aerial Placing / Mounting Outdoor
Frequency Range 1.71 – 2.17 GHz, 2.3 – 2.7 GHz, 698 – 960 MHz
Gain 1.5 dBi (for 698 – 960 MHz), 3.5 dBi (for 1.71 – 2.7 GHz)
Directivity Omni-directional
Compliant Standards RoHS
Designed For Cisco 2010, 2010 Connected Grid
Разширено описание и характеристики
General
Product Type Antenna
Product Material Polycarbonate
Width 2.5 cm
Height 24.9 cm
Weight 0.68 kg
Enclosure Colour White
Aerial
Aerial Placing / Mounting Outdoor
Frequency Range 1.71 – 2.17 GHz, 2.3 – 2.7 GHz, 698 – 960 MHz
Gain 1.5 dBi (for 698 – 960 MHz), 3.5 dBi (for 1.71 – 2.7 GHz)
Directivity Omni-directional
Voltage Standing Wave Ratio (VSWR) 2.5:1 (for 698 – 960 MHz), 2.0:1 (for 1710 – 2690 MHz)
Cabling & Wiring
Connector Provided 1 x N-Series connector female
Miscellaneous
Mounting Kit Included
Compliant Standards RoHS
Environmental Parameters
Min Operating Temperature -30 °C
Max Operating Temperature 70 °C
Compatibility Information
Designed For Cisco 2010, 2010 Connected Grid
Техническото описание е възможно да не съвсем пълно или точно. Ако имате въпроси – пишете ни.


Additional information

SKU

ANT-4G-OMNI-OUT-N
Състояние на продукта

Нов в отворена кутия. Продуктът е нов, но незапечатан. Възможно е да е тестван от сертифициран специалист, за да се докаже функционалността му и да се избегнат DoA ( Dead on Arrival ) сценарии.
Гаранция

2 Години. Вижте повече на страницата с гаранционните ни условия.
Състояние

Нов Отворена Кутия
