| Cisco Channel Interface Processor |
|
|||
| Expansion module – 10Mb LAN – AUI – 6 ports | ||||
| Group | Network Accessories | |||
| Производител | Cisco | |||
| Код на производителя | CX-EIP6 | |||
| Description | ||||
|
The EIP provides six high-speed AUI (10 Mbps) ports. Each port on the EIP supports both Ethernet Version 1 and IEEE 802.3/Ethernet Version 2 interfaces. Each Ethernet port requires an Ethernet transceiver or a media attachment unit (MAU) and a transceiver cable or attachment unit interface (AUI) to connect to the external network. The EIP firmware (microcode), which contains card-specific software instructions, resides in a ROM in socket U101.
|
||||
| Основни характеристики | ||||
| Описание на продукта | Cisco Channel Interface Processor – expansion module – 6 ports | |||
| Вид устройство | Expansion module | |||
| Form Factor | Plug-in module | |||
| Ports Qty | 6 ports | |||
| Cabling Type | Ethernet AUI | |||
| Data Link Protocol | 10Mb LAN | |||
| Data Transfer Rate | 10 Mbps | |||
| Compliant Standards | IEEE 802.3 | |||
| System Requirements | Cisco IOS | |||
| Разширено описание и характеристики | ||||
| General | ||||
| Вид устройство | Expansion module – 6 ports | |||
| Form Factor | Plug-in module | |||
| Networking | ||||
| Connectivity Technology | Wired | |||
| Cabling Type | Ethernet AUI | |||
| Data Link Protocol | Ethernet | |||
| Data Transfer Rate | 10 Mbps | |||
| Status Indicators | Collision status, power, transmit, receive | |||
| Compliant Standards | IEEE 802.3 | |||
| Expansion / Connectivity | ||||
| Interfaces | 6 x Ethernet AUI – 15 pin D-Sub (DB-15) – female – 6 | |||
| Compatible Slots | 1 x Expansion Slot | |||
| Miscellaneous | ||||
| Package Type | Retail | |||
| Software / System Requirements | ||||
| OS Required | Cisco IOS | |||
| Техническото описание е възможно да не съвсем пълно или точно. Ако имате въпроси – пишете ни. | ||||
