Description
|
|
||||
| Cisco Expansion module – serial |
|
|||
| 8 ports – T-1 – for Catalyst 5000 – 6000; uBR 7223 – 7246 | ||||
| Group | Network Accessories | |||
| Производител | Cisco | |||
| Код на производителя | PA-MC-8T1 | |||
| Description | ||||
|
The multichannel E1 and T1 Integrated Services Digital Network (ISDN) Primary Rate Interface (PRI) port adapters are single-wide modules that integrate channel service unit (CSU) functionality, data service unit (DSU) functionality, and E1 or T1 channel support into the Cisco router.
These port adapters provide four or eight independent T1 (100-ohm) or E1 (120-ohm) connections via RJ-48C connectors. Each T1 or E1 port adapter can provide up to 128 separate full-duplex HDLC fractional or full T1 or E1 channels. Individual T1 connections of the DSX-1 version of the port adapters can connect to external CSUs, to digital cross connects (DACS), or to any other equipment that uses a DSX-1 interface. |
||||
| Основни характеристики | ||||
| Описание на продукта | Cisco – expansion module – 8 ports | |||
| Вид устройство | Expansion module | |||
| Form Factor | Plug-in module | |||
| Ports Qty | 8 ports | |||
| Data Link Protocol | Serial | |||
| Data Transfer Rate | 1.5 Mbps | |||
| Network / Transport Protocol | TCP/IP, IPX/SPX | |||
| Line Rate | T-1 | |||
| Compliant Standards | ANSI T1.403 | |||
| Designed For | Catalyst 5000, 6000; uBR 7223, 7246 | |||
| Разширено описание и характеристики | ||||
| General | ||||
| Вид устройство | Expansion module – 8 ports | |||
| Form Factor | Plug-in module | |||
| Networking | ||||
| Connectivity Technology | Wired | |||
| Data Link Protocol | Serial | |||
| Data Transfer Rate | 1.5 Mbps | |||
| Network / Transport Protocol | TCP/IP, IPX/SPX | |||
| Line Rate | T-1 | |||
| Status Indicators | Port status | |||
| Compliant Standards | ANSI T1.403 | |||
| Expansion / Connectivity | ||||
| Interfaces | 8 x T1 – 8 | |||
| Compatible Slots | 1 x Expansion Slot | |||
| Miscellaneous | ||||
| Package Type | Retail | |||
| Compatibility Information | ||||
| Designed For | Cisco Catalyst 5000, 6000 ¦ Cisco uBR 7223, 7246 | |||
| Техническото описание е възможно да не съвсем пълно или точно. Ако имате въпроси – пишете ни. | ||||
